Serial to Ethernet Converter, Modbus RTU to TCP
Industrial Serial RS232 RS485 to Ethernet Converter
General Details
Basic Function
410s can realize bi-directional transparent transmission between RS232/RS485 and Ethernet
RS232/RS485 ports can work at same time, not affect each other.
Industrial Solution
Based on TI Cortex M4 Solution, signal processing more efficient and reliable.
Equipped with optimized TCP/IP protocol stack, stable and reliable, which can realize bi-directional transparent transmission efficiency.
Work Temp: -40 ~85C, Supports hardware watchdog to keep it work stable.
Registration Packet + Bi-directional Heartbeat Packet
+ Keep Alive
When 410s works as a TCP Client,it will automatically send pre-registered packets for TCP Server
to identify this TCP. Network+Serial port heartbeat packet+Keep Alive,
maintain heartbeat connection with device terminals and servers actively, ensure the stability of the system.
Multiple Working Modes
USR-TCP232-410s supports 5 work modes: TCP Server, TCP Client, UDP Client, UDP Server and HTTPD Client.
Configure simply and it can realize data transmission.
TCP Client
TCP Server
UDP Client
UDP Client is a connectionless transport protocol.
In this mode, 410S can only communicate.
with the target port of the target IP
UDP Server
In UDP Server mode, the data received by serial port
is automatically sent to the network
target of the last communication.
Httpd Client
Characteristic Function Collection
Virtual COM
Solve the problem that PC software cannot
communicate with network and equipment as a serial port.
Identification of broken network, automatically wired
Solve the identification of dead links easily, automatic
reconnection, prevent data loss due to power outages,
disconnection.
Modbus gateway
Polling mechanism can solve the problem of sticky congestion
effectively, which is caused by data concurrency.
Customize built-in webpage for users Web to Serial
Design built-in webpages according to project requirements
and realize webpage control, web page data acquisition
and other functions.
Electrical Fire Network Monitoring
410S communicates with the RS232/485 serial port of the electric fire alarm, and transmits the alarm
information to the cloud platform quickly to remind the staff to eliminate the fire.
Smart Lighting Facilities in Factories and Mines Monitoring
The traditional lighting facilities in factories and mines are mostly controlling by people,
and cannot realization linkage between manufacture and monitoring, and lead to energy wasting.
410s communicates with serial lighting equipment via network,
it is convenient for lighting control and can initiative report the mistakes of the equipment.
Water Supply System Monitoring
Recently the hoc communication of water supply system in waterworks is still based on serial,
and it is only suitable for single-machine operation and limited transmission distance, system maintenance is difficult.
410s supports serial port to network, monitor the work of the equipment via TCP Server mode at any time.
Basic Function
410s can realize bi-directional transparent transmission
between RS232/RS485 and Ethernet. RS232/RS485
ports can work at same time, not affect each other.
Industrial Solution
Based on TI Cortex M4 Solution, signal processing
more efficient and reliable. Equipped with
optimized TCP/IP protocol stack, stable and
reliable, which can realize bi-directional
transparent transmission efficiency.
Work Temp: -40 ~85C, Supports hardware watchdog
to keep it work stable.
Registration Packet
+ Bi-directional Heartbeat Packet
+ Keep Alive
When 410s works as a TCP Client,it will automatically
send pre-registered packets for TCP Server to
identify this TCP. Network+Serial port heartbeat
packet+Keep Alive, maintain heartbeat connection with
device terminals and servers actively, ensure the
stability of the system.
Multiple Working Modes
USR-TCP232-410s supports 5 work modes:
TCP Server, TCP Client, UDP Client,
UDP Server and HTTPD Client.
Configure simply and it can realize
data transmission.
TCP Server
UDP Client
UDP Client is a connectionless transport protocol.
In this mode, 410S can only communicate.
with the target port of the target IP
UDP Server
In UDP Server mode, the data received by
serial port is automatically sent to the
network target of the last communication.
Characteristic Function Collection
Virtual COM
Solve the problem that PC software cannot
communicate with network and equipment
as a serial port.
Identification of broken network,
automatically wired
Solve the identification of dead links easily,
automatic reconnection, prevent
data loss due to power outages,
disconnection.
Modbus gateway
Polling mechanism can solve the problem
of sticky congestion effectively,
which is caused by data concurrency.
Customize built-in webpage for users
Web to Serial
Design built-in webpages according to
project requirement
Electrical Fire Network Monitoring
410S communicates with the RS232/485 serial port of the electric fire alarm, and transmits the alarm
information to the cloud platform quickly to remind the staff to eliminate the fire.
Smart Lighting Facilities in Factories and Mines Monitoring
The traditional lighting facilities in factories and mines
are mostly controlling by people, and cannot
realization linkage between manufacture and
monitoring, 410s communicates with serial lighting
equipment via network, it is convenient for
lighting control and can initiative report
the mistakes of the equipment.
Water Supply System Monitoring
Recently the hoc communication of water
supply system in waterworks is still based on
serial, and it is only suitable for single-machine
operation and limited transmission distance,
system maintenance is difficult. 410s supports
serial port to network, monitor the work of
the equipment via TCP Server mode at any time.
Specifications
| System Information | |
| Processor | Cortex-M4 |
| Basic Frequency | 120MHz |
| Flash | 512K byte |
| Ethernet | |
| Port Number | 1 |
| Interface Standard | RJ45 |
| Rate | 10/100 Mbps MDI/MDIX, auto switch between cross and direct connection |
| Protection | 2KV electromagnetism isolation, shell insulation blocking |
| Network Protocol | IP, TCP, UDP, DHCP, DNS, HTTP, ARP, ICMP, Web socket, Httpd client |
| Receive Buffer | Max 16k bytes buffer |
| Serial | |
| Port Number | 2 (1*RS-232, 1*RS-485, can work at the same time) |
| Interface Standard | RS-232: DB9 pin type, RS-485: 3 wire (A+, B-, G) |
| Data Bits | 5, 6, 7, 8 |
| Stop Bit | 1, 2 |
| Check Bit | None, Even, Odd, Space, Mark |
| Baud Rate | RS-232: 600 bps ~ 230K bps, RS-485: 600 bps ~ 1M bps |
| Flow Control | RTS/CTS |
| Buffer | Send and receive 2k bytes respectively |
| Protection | RS-485: anti-static 2KV, lightning protection |
| RS-485 Pull-up and Pull-Down Resistor | 2.2 KΩ |
| Software | |
| Virtual Serial（USR-VCOM） | Windows 2000 or higher (32 bit/64 bit) |
| Configuration | Built-in webpage, computer set-up software, serial command |
| Basic Parameter | |
| Size | 80 x 62 x 24 mm |
| Operating Temp. | -40 ~ 85°C |
| Storage Temp. | -45 ~ 105°C, 5 ~ 95% RH |
| Input Voltage | DC 5 ~ 36V |
| Working Current | 44.3mA(aver)@ 12V |
| Power | <1W |
| More | |
| Certificate | CE,FCC,ROHS |
| Warranty | 2 years |
| Accessory | 5V1A high-quality power supply, serial line, cable |
